Rogi WMD20LV brushless drill-mill
Rogi WMD20LV brushless drill-mill
Contact us for price
Location:Mierlo, Netherlands
Description
Powerful brushless 750W motor
Belt drive
Compact, accurate variable speed drilling & milling machine Spindle feed via cross lever for drilling Fine adjustable crossfeed for milling Stepless electronically controlled drive Easy operating safety switch with low voltage release and emergency stop Massive and precisely finished cross table, large dimensioned Drilling/milling head rotating by ± 90° Solid dovetail slideway, providing highest stability and upmost precision Easy reading work table scale has satin chrome finish Digital depth ruler, accuracy of the display 0.01 mm, reversible mm/inch Easy to read speed counter Equipped with emergency stop button
Options
3-axis digital readout system SINO
Stand
Milling vise
Milling chuck holder MT2 and collets
Mill cutters
Clamping kit
Specifications
Manufacturer | Rogi |
Model | WMD20LV BRUSHLESS |
Condition | New |
Drilling capacity | 20 mm |
End milling capacity | 16 mm |
Face milling capacity | 63 mm |
Table size | 700 x 180 mm |
Table travel | 490 x 155 mm |
T-slot | 12 mm |
Spindle taper | MT2 |
Spindle stroke | 50 mm |
Step of spindle speeds | Variable |
Range of spindle speeds | 100 - 3000 rpm |
Spindle incline angle | 90º |
Distance from spindle to column | 201 mm |
Distance from spindle nose to table | 280 mm |
Motor | Brushless 750W |
Power supply | 230V-1PH-50HZ |
Packing size | 710 x 710 x 900 mm |
Weight | 135 kg |
